SIMATIC S7-200 series, 6ES7214-2AD23-0XB0

The Siemens 6ES7214-2AD23-0XB0 is a compact programmable logic controller (PLC) from the SIMATIC S7-200 series, designed for small to medium-scale automation tasks. It offers a combination of digital and analog I/O capabilities, making it suitable for applications requiring precise control and monitoring.

? Key Specifications

• Model: CPU 224XP
• Power Supply: 24 V DC (permissible range: 20.4 V to 28.8 V)
• Digital Inputs: 14 (DC)
• Digital Outputs: 10 (DC, relay)
• Analog Inputs: 2
• Analog Output: 1
• Program Memory: 12/16 KB
• Data Memory: 10 KB
• Communication Ports: 2 PPI (Point-to-Point Interface) / Freeport ports
• Encoder Supply: 24 V DC, short-circuit protected, max. 280 mA
• Power Loss: Typical 8 W
• Inrush Current: Max. 12 A at 28.8 V
• Weight: Approximately 0.376 kg
• Product Lifecycle: Product cancellation (PM410) since 01.10.2017

⚙️ Features and Capabilities

• Expandable I/O: Supports additional modules for increased I/O capacity.
• Flexible Communication: Equipped with two PPI / Freeport ports for versatile communication options.
• Analog Processing: Includes analog inputs and outputs for handling continuous signals.
• Compact Design: Space-saving form factor suitable for installations with limited space.
• Integrated Power Supply: Eliminates the need for an external power supply unit.

✅ Applications

The 6ES7214-2AD23-0XB0 is ideal for:

• Machine Automation: Controlling and monitoring machinery in manufacturing processes.
• Process Control: Managing continuous processes requiring analog signal processing.
• Building Automation: Implementing control systems in HVAC and lighting systems.
• Packaging Systems: Automating packaging lines with integrated digital and analog control.
