SIMATIC KTP700 COMFORT HMI PANEL

KTP700 Comfort

• SIEMENS SIMATIC HMI
• Model: 6AV2123-2GA03-0AX0

·       6AV2124-0GC01-0AX0

Key Features of the KTP700 Comfort

1. Display & Touchscreen

• 7-inch TFT LCD with 16 million colors (true high-color display).
• Resolution: 800 × 480 pixels (WVGA).
• Projected capacitive touchscreen (multi-touch support) – smoother and more responsive than resistive touch.
• LED backlight for bright, energy-efficient operation.

2. Design & Durability

• IP65 protection rating (front panel – dust-tight & protected against water jets).
• Aluminum-magnesium housing for rugged industrial environments.
• Wide operating temperature range (0°C to 50°C).

3. Connectivity & Interfaces

• 1 × PROFINET (Ethernet) port for PLC communication (S7-1200, S7-1500, etc.).
• 1 × USB 2.0 host port (for project transfer, scripts, or USB peripherals).
• Optional: PROFIBUS DP/MPI module (for legacy Siemens PLCs).

4. Memory & Performance

• 128 MB RAM / 512 MB Flash (for faster performance and larger projects).
• Supports TIA Portal (WinCC Comfort/Advanced/Professional).
• Integrated web server for remote diagnostics.

5. Power Supply

• 24V DC (standard industrial power).

6. Mounting Options

• Panel-mounted (cutout dimensions: 215 × 158 mm).
• VESA mount compatible (optional).

Comparison with KTP BASIC Panels

Typical Applications

• Advanced process visualization (chemical, pharmaceutical, food & beverage).
• Machine control with multi-touch gestures (zooming, swiping).
• Remote monitoring via web server.
• Integration with high-end Siemens PLCs (S7-1500, ET 200).

Software Compatibility

• TIA Portal (WinCC Comfort/Advanced/Professional) for full-featured HMI development.
• Supports HTML5, JavaScript, and advanced scripting.
